Manual roll cutter,Roll cutting machine,Manual roll cutting machine,Electrical roll cutting machine,Semi auto film foil fabric PVC roll cutting machine equipment
|
| PM-C1300 |
| |
| |
Features: |
| |
- Suitable for manual cutting roll materials of double-sided tape, kraft paper, masking, foam, PVC, Cloth and fabric etc.
- Equips with circular cutting knife, manual feeding and cutting.
- With hexagonal positioning measurement for the roll cutting width, fast and accurate positioning.
- Small structure, easy to operate and maintain, cost effective.
- Professionally Manufactures and Wholesales Manual roll cutter,Roll cutting machine,Manual roll cutting machine,Electrical roll cutting machine,Semi auto film foil paper fabric PVC roll cutting machine equipment etc.
- Special roll and size cutting machine can be custom made.
|
| |
Main Specifications: |
| |
- Max roll width: 1300 mm
- Max cutting width: 3-1300 mm
- Max cutting diameter: 170mm
- Max roll cutting speed: 35Pcs/minute
- Diameter of inner paper core: Ø32~Ø76.2mm
- Cutting precision: ±0.2mm
- Spindle motor power: 2HP/1.5KW
- Circular cutter power: 1HP/0.75KW
- Inner diameter of circular cutter: 2mmX25mmX200mm
- Circular cutter speed: 0-1400rpm/min
- Machine Power Supply: 3P,380VAC,2KVA
|
| |
|
|
|
|
