Roll heat transfer label screen printing machine,Automatic roll heat transfer label screen printer,Auto heat transfer foil paper or film screen printing equipment with hot air drying cabinet

Roll heat transfer label screen printing machine,Automatic roll heat transfer label screen printer,Auto heat transfer foil paper or film screen printing equipment with hot air drying cabinet

PM-S200A1CR / S400A1CR

  Features:

  • Professionally design and manufacture roll heat transfer label screen printing machine,Automatic roll heat transfer label screen printer,Auto heat transfer foil paper or film screen printing equipment with hot air drying cabinet.
  • Our roll heat transfer label screen printing machine,Automatic roll heat transfer label screen printer,Auto heat transfer foil paper or film screen printing equipment with hot air drying cabinet is designed and tailored to the single color to multi color silk screen printing on roll substrate products such as PET, PVC, transfer paper (film), floor heating film, geothermal film, electric film, flower paper, film, nameplate, flexible circuit board, mobile phone keypad, 3M adhesive, glue, membrane switch, laser trademark , Scratch cards, self-adhesive labels, drummed paper, webbing, aluminum foil, copper foil and other web material.
  • With auto winding, auto silk screen printing, auto IR hot air drying and auto rewinding etc.
  • Integrates with variable frequency motor, servo motor, PLC and touch screen etc for good and easy operation control.
  • Multi-color printing with automatic electric eye alignment, automatic detection of color,automatic shutdown if it gets abnormal.
  • Equips with servo motors, the screen printing length and ink scraping speed etc can be set easily.
  • Automatically calculates the printing number, and you can set the total automatic printing number as you want.
  • Electronic eyes control material feeding and delivery in order to avoid surface scratches and improve the printing quality.
  • Uses Japanese brand precision regulator and high precision electronic eyes.
  • Equips with dedusting roller to remove dust on the material.
  • Equips with the screen-peeling function to prevent the sticky during the screen printing on large area and glue printing.
  • Applies a three-stage vacuum device - strong, middle and weak, according to the printing material requirements to make good adjustment.
  • With circulating hot air drying, temperature adjustable ,automatic winding.
  • The drying cabinet ranges from 32-60 meters in length, can achieve low-temperature drying, and protects the printed material does not shrink deformation, which will help multi-color printing.
  • The drying cabinet has insulation material for insulation and energy saving.
  • Different size requirement can be custom made.



  Main Specifications:

Models PM-S200A1CR PM-S400A1CR
Max feeding width 200mm 400mm
Max screen printing area 180x380mm 360x660mm
Screen printing table size 300x500mm 400x700mm
Max s screen frame size 600x800mm 700x1000mm
Printing substrate thickness 0.03~0.4mm 0.03~0.4mm
Printing Accuracy ±0.05-0.1mm ±0.05-0.1mm
Max winding and rewinding diameter 500mm 500mm
Air supply 0.6~0.75Mpa/cm2 0.6~0.75Mpa/cm2
Power supply 3 phase 380V 12Kw 3 phase 380V 30Kw
IR drying power 10kw 25kw
Max drying temperature 130℃ 130℃
Screen printing machine dimension 2000×1000×1600mm 2800×1200×1680mm
Drying cabinet dimension 1800×800×1600mm 2300×1050×2000mm
Machine total length 5000mm 7000mm
Machine weight 980kg 1380kg




Roll heat transfer label screen printing machine,Automatic roll heat transfer label screen printer,Auto heat transfer foil paper or film screen printing equipment with hot air drying cabinet
